Album: Public (ksd050)

by ksd050
For ages I was convinced I should use the 5mm steel plates from the original bench saw.. but after 2 failed attempts I gave up and used formply
lifting mech fitted to bring the saw up onto castors
Building the fence
Many clamps
new, Formply tabletop with messmate edging
fence rail attached to table top
table top to base attached via T nuts
Shiny!
Tabs at the back to attach table top, allow for adjustment
Wing bolts in oversize hole at the front allows for adjustment between table top and blade
Routed out blade insert using a template... forgot to photograph that
Done
All square
Cutting rebate for rails
Using fence as straight edge
Stick on tape on fence rail allows for quick, accurate cuts
More formply for front and sides, getting the height adjustment and tilting lock cutouts right was very testing
Previous
Next
Added March 2020
0 Likes
Like
Posted in: Re: DIY height adjustable, tilting table saw from 60's bench saw - ( March 2020 )
